M12x25x6mm Cylinder Double Cut Carbide Burr With End Cut

Product Description

M12x25x6MM CYLINDER DOUBLE CUT CARBIDE BURR WITH END CUT

The B122506-DC Double Cut Carbide Burr is a professional-grade rotary cutting tool designed for fast stock removal, deburring, shaping and finishing on a wide range of metals. Featuring a 12mm diameter cylindrical head with end cut, it allows effective cutting on both the sides and end of the burr, making it particularly useful for working on flat surfaces, internal profiles and confined areas.

Manufactured with a carbide cutting head and brazed steel shank, the double cut tooth pattern provides efficient material removal while producing smaller chips and improved operator control. It is suitable for demanding fabrication, engineering, maintenance and metalworking applications.

Key Features

Double cut tooth pattern for fast, controlled material removal
Cylindrical shape with end cut for side and end cutting
12mm diameter carbide cutting head
25mm head length for effective stock removal
6mm steel shank for use with compatible rotary tools
Brazed construction for strength and durability
Produces smaller chips for improved control and surface finish
Suitable for a wide range of ferrous and non-ferrous metals
Ideal for professional fabrication, engineering and maintenance work

Ideal Applications

Deburring
Weld dressing
Stock removal
Edge preparation
Surface levelling
Enlarging and shaping openings
Removing sharp edges
Cleaning castings
General metal shaping and finishing

Suitable Materials

Steel
Stainless Steel
Cast Iron
Titanium
Nickel
Copper
Compatible Machines
Die Grinders
Straight Grinders
Suitable Rotary Tools with a 6mm Collet

Specifications

Product Code: B122506-DC
Product Type: Double Cut Carbide Burr
Shape: Cylindrical with End Cut
Type: B
Cutting Head Diameter: 12mm
Head Length: 25mm
Shank Diameter: 6mm
Overall Length: 70mm
Construction: Carbide Head with Brazed Steel Shank
Cut Type: Double Cut
Recommended Minimum Speed: 12,000 RPM
Recommended Maximum Speed: 16,000 RPM
Operating and Safety Information

For optimum performance, operate the burr between 12,000 and 16,000 RPM. Running the burr too slowly can cause chipping, while excessive speed can result in premature wear.

Avoid excessive pressure and heat build-up during operation. As this is a brazed carbide burr, excessive heat can weaken the brazed joint and potentially cause the carbide head to detach from the shank.

Always wear appropriate PPE, including eye or face protection, gloves and hearing protection, and ensure the burr is securely fitted to the machine before operation.

The B122506-DC 12mm Double Cut Cylindrical Carbide Burr provides fast material removal, excellent control and dependable performance, making it ideal for professional fabrication, engineering, automotive and industrial metalworking applications.
